NetworkHD Routing
Switch video, audio and USB in a WyreStorm NetworkHD system from any RTI panel, remote or keypad — with true feedback.
Overview
One driver controls the whole NetworkHD system through the NHD-CTL controller: up to 32 sources and up to 32 displays, switched from any RTI panel, remote or keypad. Video, audio and USB can move together or separately, so a room can keep its camera and microphone on one PC while the picture changes.
Every display and every source gets its own group of ready-made functions and variables, named the way you name the room. Drag Main Screen – Set Source onto a button and the work is done; nothing has to be typed twice. Use Display – Source variables for highlighted buttons, Routed Display Count for the room overview, and the driver’s events — routed, unrouted, display offline, video lost, controller disconnected — to start your own macros.
Maintenance is covered too: reboot one decoder, one encoder, all endpoints or the controller from the panel, and send your own named commands as ready-made buttons. Multiview decoders are not part of this driver — they have their own.
What you can do
Any source on any display — in one tap
Send any source to any display, to all displays at once, or step through sources with one button. Two panel styles: a direct button per source and display, or “select a source, then tap the displays”. Up to 32 sources and 32 displays through one NHD-CTL controller.
Buttons show what is really on screen
A button lights up the moment it is pressed and goes back if the controller does not confirm the change. Every display reports online, picture present, no-video alarm, resolution, HDCP and stream state; every source reports online, signal and streaming.
Whole-room layouts as one button
Save the routing of the whole room and recall it with one button — presets survive a processor restart. CEC power and input commands for displays, RS-232 to any encoder or decoder, USB switching on its own, and events for macros: routed, display offline, video lost, controller disconnected and more.
What’s inside
What you download after purchase — the full package, ready to drop into a project.
The driver
RTI XP driver for the NHD-CTL controller: switching, USB, presets, device control, status variables and events.
networkhd-routing-2.6.rtidriverSetup instructions
Six steps from controller IP to a working panel, two switching styles, feedback variables — inside the driver.
instructions.rtfYour licence key
Bound to the processor MAC, delivered as a text file by e-mail.
AVRELAY_NetworkHD-Routing_<MAC>.txtUpdates
New releases of the driver on request, no extra charge.
by e-mailBuy a licence
One licence per RTI processor, bound to its MAC address.
